کنترلر ایجاد ویدئووال با دیتا پروژکتور

این دستگاه قادر به ایجاد ویدئووال نامنظم و نامتقارن با انواع ویدئو پروژکتور می باشد .

مشخصات فنی

• Four edges blending up to 15×15 matrix display from single signal.
• Multiple input ports for multiple signal connection.
• Programmable EDID and support None VESA standard input timing.
• Precise geometry alignment, max. up to 17×17 grid pattern.
• Image PIP/POP, flip, rotation and warping.
• Edge blending for curved, 360 degrees and irregular surface.
• Edge blending with projector at portrait position.
• Edge blending with multiple discrete PC in simulation system.
• Edge blending for active and passive 3D.
• Embedded video wall function, no image splitter is required.
• ۴K loop out port for daisy chain connection in cascade application.
• Easy to achieve super high resolution edge blending.
• Precise gamma and color fine-tune in edge blending region.
• White balance correction and accurate black level uplift.
• Programmable EDID setting.
